    Swing Robinia 8

    Code: 02-ROB-203-BS

    Technical data sheet:
    pobierz pdfPDF pobierz pdfDOC
    Technical drawings:
    download pdf PDF download dwg DWG
    3D Models:


    This product you can also find in sections:

    Description

    A double pendulum swing with a bucket seat and a plank seat. The sturdy construction is made from the highest quality ROBINIA wood, which combines a natural ecological appearance with exceptional durability. The wood is resistant to harsh weather conditions. The swing is finished with decorative elements featuring forest motifs (owls).

    Playground device consists of

    • 1 bucket seat suspended on chains
    • 1 plank seat suspended on chains
    • 4 swing legs
    • 1 crossbeam
    • Decorative elements with forest motifs (owls)

    Product details

    • Dimensions: (LxWxH): 2,38 x 3,89 x 2,48 m
    • Safety area: (LxW): 7,50 x 3,17 m
    • Freefall height: 1,34
    • Age group: 3-12
    • Number of users: 2 people
    • Differences in dimensions no more than +/- 5% are acceptable

    Materials

    • Construction made of ROBINIA wood, beams approximately 16 cm thick,
    • Crossbeam made of stainless steel,
    • Connecting elements made of stainless steel,
    • Seat board made of aluminum construction, covered with soft EPDM rubber, suspended on 6 mm diameter stainless steel chains.
    • Basket seat with a construction combining aluminum and stainless steel, covered with soft polyurethane.
    • All screws exposed to weather conditions are made of stainless steel.
    • Decorative elements made of 15 mm thick HDPE material.

    All images are for illustration purpose only and may vary from the actual product.
