    TWO TRIANGULAR HANDLES

    Code: KS-SW-14a

    Technical data sheet:
    pobierz pdfPDF
    Technical drawings:
    pobierz pdfPDF pobierz dwgDWG
    3D Models:
    pobierz dwgDWG

    Description

    Two triangular handles fixed to construction post, intended for teenagers and adults. The structure is made of galvanized and powder coated steel. Training on the handles strengthen muscles of the chest, back, arms, shoulders and abdomen. Training on it improves sense of balance and motor coordination.

    Product details

    • Dimensions (LxWxH): 0,70 x 0,68 x 2,50 m
    • Safety area: 3,70 x 3,68 m
    • Distance from the handle to the ground: 1,20 m
    • User’s maximum weight: 150 kg

    Dimension tolerance is +/- 5%

    Materials

    • Galvanized and powder painted steel - the devices are painted in green (RAL 6003) and grey (RAL 9006). On request other RAL colors may be used.
    • Construction posts with square profile 80x80 mm (thickness 3 mm),
    • Rounded profile bars with diameter 42,4 mm
    • Screws covered by polymer caps.
