Slalom, the device intended for teenagers and adults, consisting of 2 rails to which 6 curved pipes formed as a slalom passage are fixed. The structure is made of galvanized and powder coated steel. Training on the slalom device affects the sense of balance and improves motor coordination.

  • Dimensions (LxWxH): 2,16 x 1,00 x 1,40 m
  • Safety area (LxW): 5,16 x 4,00 m
  • Freefall height: 0,3 m
  • Number of users: 1
  • Height of the bar: 1,3 m
  • Distance between the rails: 0,84 m
  • User’s maximum weight: 150 kg
  • A certificate confirming compatibility with norm EN 16630
  • Differences in dimensions no more than +/- 5% are acceptable
  • Galvanized and powder painted steel - the devices are painted in green (RAL 6013) and grey (RAL 9006). On request other RAL colors may be used.
  • Construction posts with square profile 80x80 mm (thickness 3 mm),
  • Rounded profile bars with diameter 42,4 mm
  • Screws covered by polymer caps.

All images are for illustration purpose only and may vary from the actual product.
